RadiPac centrifugal fans
for central air conditioning units in large buildings

Special challenges
require special fans

As living and working space becomes increasingly expensive, space-saving central ventilation systems are usually preferred. This means that the air has to travel long distances through external components for air treatment and long air ducts around many corners and branches.

In order to offer a suitable solution for precisely this application, ebm‑papst has optimized its popular RadiPac series for the specific conditions – with high volume flows or high static pressure increases, depending on requirements.

RadiPacs with high static pressure

(Air) resistance is futile!

If ventilation requires covering long distances or passing through additional “obstacles” such as activated carbon filters, heat exchangers, and separators, the fan must overcome high back pressure.

For these cases, ebm‑papst has developed powerful RadiPac centrifugal fans with a particularly high static pressure increase – which are also compact, efficient, and reliable.

RadiPacs with high static pressure offer:

Up to 2,500 Pa
Available in sizes 355, 400, 560, 630
Spider or cube design
Easy commissioning thanks to plug & play

RadiPacs for large volume flows

Move more with just one fan

To maintain consistent air quality in airports, shopping centers, high-rise buildings, and hotels, large volumes of indoor air must be circulated by the central ventilation system.

For these cases, ebm‑papst has equipped the RadiPac M centrifugal fans with the most powerful EC external rotor motor in its class, achieving volume flows of up to 50,000 m³/h – an increase of approximately 25% compared to the previous model. And that with just one fan.

What RadiPacs with high-performance EC drives offer:

Sizes 710 and 800 with EC external rotor motors up to 24 kW
Volume flows up to 50,000 m³/h
Highly efficient EC drive without rare earths
Ready-to-install cube design with compact transport dimensions
Easy installation via plug & play

Your RadiPac collection
for central air conditioners in large buildings

Go to ebm‑papst FanScout now and receive suitable product recommendations for your application.

To RadiPac Collection

All information at a glance:

RadiPac brochure with high static pressure
Includes characteristic curves, dimensions, system components, and advantages

RadiPac M brochure, sizes 710 and 800, with high-performance EC drive up to 24 kW
Includes RadiPac M functionality, performance data for sizes 710/800, system components, and advantages

Download flyer
