Efficient fans and drive concepts for rail technology.

Everything in motion.

Our contribution as a technological partner: AC and EC drives that are characterised by their maximum performance, dynamics and accuracy of speed. Energy and space-saving ventilation systems that are indispensable in modern traffic technology thanks to their high pressure consistency, low noise levels and long service life. They open doors and windows, regulate switches and signals, air condition passenger compartments and cool technical infrastructure.

This is where our sustainable solutions help to ensure a good journey by train, tram or subway:

Rail_01

The driver's cab and passenger compartment are air-conditioned so that both drivers and passengers reach their destinations in comfort. This makes traveling and working on trains more pleasant and enjoyable. The necessary air is conveyed by our axial and centrifugal fans, which are specially designed to meet the requirements of rail technology. They are particularly energy-saving, low-noise and offer high pressure consistency. What’s more, they can be easily and individually controlled and are, of course, also vibration and shock tested. All fans can be connected to the relevant on-board power supply.

Rail_02

If door systems in subways, commuter trains, or even high-speed trains malfunction, it is annoying, inconvenient, and expensive. That's why our door drives ensure that train doors open and close smoothly, silently, quickly and safely without barriers. Depending on the requirements, planetary gear units, combinations of angular and planetary gear units or special gear units are used for this task. All solutions are characterized by their enormous reliability and speed accuracy.

Rail_03

Converters convert the high voltage of overhead lines so that it can be used for the various consumers on the train. Since heat is generated during conversion, the converter must be cooled. Our durable RadiCal centrifugal fan does this with ease - in a low-noise and electromagnetically compatible way.

Rail_02

Boarding aids make it easier for passengers to enter and exit the train, thereby providing increased comfort and accessibility. A three-stage spur gear extends sliding steps and holds them in the required position. Special angular gearboxes with combined planetary and crown gearhead technology are used to retract and extend folding steps and moving ramps.

Rail electronics are subjected to different levels of stress in different running conditions. In addition, any power losses that occur for power generation, transmission and distribution must be dissipated quickly and efficiently. The technology required for cooling must be correspondingly flexible and, above all, consistently effective.

Our energy- and space-saving fans are ideally suited for this purpose. They are quiet, durable, and can be used in a wide range of configurations and performance classes. Across all versions, they feature impressive electromagnetic compatibility, high pressure stability and bus control capability.

We ensure our competitive edge through the perfect interaction of all components.

For our pioneering application solutions, we always consider the perfect interaction of motor technology, electronics and aerodynamics – and not just the individual components. This enables us to make optimum and highly efficient use of air and motion, as well as intelligent connections. Whether in confined spaces, large dimensions or under extreme environmental conditions.

We use our many years of experience when designing our products to bring benefits to you in the relevant application-specific environment. We use real conditions to perfectly hone our solutions to meet the requirements of rail technology. We attach great importance to the seemingly smallest details on the fan blades, fan wheels and drives. The result is significant improvements in terms of efficiency and noise. Our many years of industry expertise make us the ideal engineering partner and innovative system manufacturer of drive and fan solutions for rail technology.

Perfect for out and about.
The AxiEco Track for railway technology.

Do you have any individual questions?

We look forward to working together. Feel free to get in touch with our experts.

Efficiency requirements and standards

It goes without saying that our fans meet all the necessary efficiency requirements and standards for use in rail vehicles:

  • EN 45545 2:2020 Fire protection on railway vehicles
    The fans satisfy the requirements of HL3 (certified by TÜV Süd). The fire protection requirements of the entire system must be assessed separately.
  • EN 50121-3-2: 2016 Electromagnetic compatibility
  • EN 50155: 2017 Electronic equipment used on rolling stock
  • IEC 61373: 2010 Shock and vibration tests
    The fans are tested in accordance with Category 1B. The entire system must be tested separately.
  • EN 15085-1/3: 2013 Welding of railway vehicles and components Weld quality CPC3

You can find all details on our product solutions for rail technology in our product catalog.

The catalog contains:

  • All fans and drive concepts for rail technology
  • Performance data and dimensions
  • Accessories
  • Connection diagrams
AxiEco_Perform_W-Typ_EC_Perspektive_Back

AxiEco Track

The entire series impresses with its robust, compact and extremely low-noise design. In sizes 300, 400, 450 and 500, the AxiEco Track meets all industry-relevant standards.

Find out more

AxiForce_120_mm-frei-_20803

AxiForce

The new AxiForce compact fan series ensures that sensitive future technologies are effectively protected. And noise emissions are kept nicely within limits.

Find out more

DiaForce

DiaForce

Not only strength, but also brains: The new DiaForce has a conical cover plate that rotates with it. The outlet opening is larger than the intake opening. The air flows through the fan in both an axial and a radial direction, enabling a high pressure increase.

Find out more

Doppelradialgebläse

Double centrifugal blower for rail applications

DC_Motor_BCI

DC Motor BCI and angular gearboxes

Our angular gearboxes feature innovative crown gearhead technology – enabling strong, compact, durable and highly efficient transmission solutions that can be produced very economically.

Find out more

DC_Motor_ECI_Planetengetriebe

DC Motor ECI and Performax®Plus planetary gear

Performax®Plus stands for smooth operation and powerful performance. This is made possible by helical planetary gears made of high-strength plastic combined with a hardened ring gear in the output stage.

Find out more
