Tangentialfan

Tangential blowers

Low noise with high air flow rates and low back pressures.

Stable performance to meet all requirements

Stove jacket cooling, storage heaters, wood-burning stoves, underfloor convectors, air doors, air conditioners and heaters – all of these applications need a ventilation system offering low installation height and high air flow rates. The ideal solution: Tangential blowers from ebm-papst. These provide high air flow rates, excellent air throw, and extremely good noise characteristics.

The generally small impeller diameter (30 to 65 mm) to impeller length (up to 2×300 mm) ratio permits an extremely shallow, flat design. The large intake and outlet cross-section makes it possible to achieve a high air throughput rate with low flow velocities. Further characteristic features of tangential blowers are a long air throw and extremely low running noise.

Tangential blowers are available with an asymmetrical shaded-pole motor, a capacitor motor or a GreenTech EC motor with integrated commutation electronics (incl. tach output and PWM or analog input) to suit the application concerned. With the GreenTech EC motors it is possible to select a higher speed than for shaded-pole and capacitor motors, to overcome higher back pressures for example. Using appropriate sensors, the tangential blower featuring GreenTech EC technology automatically sets the required operating points and conveys the exact amount of air required.

Tangentialfan

The advantages of ebm-papst tangential blowers at a glance:

  • Low noise with high air flow rates and low back pressures
  • High air throughput with low flow velocities
  • Expanded-width discharge area ensures that air makes good contact with ducts and surfaces to be cooled
  • Extremely shallow design
  • Moisture-proof versions for refrigeration applications, for example
  • Higher speeds with GreenTech EC motors than with AC motors
  • Power adjustment via PWM signal or 0–10 V analog voltage

Product search for tangential blowers

Not all products are availble in North America. Please contact your local sales rep or click here.

Items per page
25 25 50 50 100 100

{{filteredItems.length}} matching products found

Active filters:

{{filterVoltageV}} V {{filterVoltageType}} Voltage {{filterDimensions}} mm {{filterPhase}} {{filterFrequency}} {{filterPeriphery}} {{filterAirflowMin}} - {{filterAirflowMax}} m3/h {{filterSoundPressureMin}} - {{filterSoundPressureMax}} dB(A) {{filterSpeedMin}} - {{filterSpeedMax}} min-1 {{filterNominalTorqueMin}} - {{filterNominalTorqueMax}} mNm {{filterNominalCurrentMin}} - {{filterNominalCurrentMax}} A {{filterPowerOutputMin}} - {{filterPowerOutputMax}} A

Type Speed
in min-1
Phase Connection Airflow
in m³/h
Nominal voltage
in V
Max. back pressure
in Pa
Frequency
in Hz
AC/DC
Type {{item.TYP}} Speed in min-1 {{item.DREHZAHL}} Phase {{item.PHASE}} Connection {{item.VERSCHALTUNG}} Airflow in m³/h {{item.LUFTLEISTUNG}} Nominal voltage in V {{item.SPANN_BEREICH_DISPLAY}} Max. back pressure in Pa {{item.GEGENDRUCK}} Frequency in Hz {{item.FREQUENZ}} AC/DC {{item.SPANN_AC_DC}}

Loading data...

No products found for your selection.
